- Size: 30
- Place of Origin: China
- Brand Name: truckmore
- Model Number: 2HAL-camper
- Weight: 2000.000 kg
Materials | Chassis Material | double hot dip galvanized RHS (3.5mm-4.0mm) |
Frame Material | double hot dip galvanized RHS (2.5mm) | |
Body Panel | galvanized sheet (1.2mm) | |
Roof | special molded FRP | |
Nuts &bolts | stainless steel | |
Drawbar | Drawbar Checker Plate | 1.2mm aluminium |
Drawbar Safety Chain | 2 | |
Swing-up jockey wheel | 1 | |
Suspension & Axles | Suspension | 9-leaf Roll rocker tandem spring |
Axles | 2*45*45mm solid axle | |
Break system | two axle electric brakes with hand brake cable | |
Wheels & Tyre | Wheel rim | 14’ aluminum alloy rims |
Tyre | 185R14C | |
Spare wheel | one | |
Rubber | Inner Side Panel | 10mm Rubber |
Floor | 18mm plywood and 10mm Rubber | |
Ramp Door | 18mm plywood and 10mm Rubber | |
Mudguard | Mudguard type | compact mudguard |
Mudguard checker plate | 1.2mm aluminium | |
Pedal &aluminium step | 1.2mm aluminium decoration board | |
Windows & Doors | Front Window | 1220*610mm |
Side Windows | 3x multifunction pop-up windows with fence and 2x slide windows with flyscreen | |
Vents | 2 | |
Rear Upper Door | 2020*1065mm | |
Ramp Door | 2020*1210mm | |
Side Door | 1750*610mm | |
Rear upper&ramp door strut | High-intensity anti-rust strut | |
Hinges for Rear Upper Door | special 6mm diameter copper hinges | |
Lights | Trailer Plug | square or flat Seven-core Plug |
Rear Lights brackets | aluminium plate protect / just square tube bracket | |
LED interior lights | 1 | |
LED sidelights | 6 | |
LED combination taillights | 2 group | |
Auxiliary Fitting | Cupboard | front |
Horse Protection Frame | fully padded | |
Horse Ring | 3 | |
Rug Rack | full length side rug rack | |
Saddle Rack | three saddle rack in the aluminum saddle box | |
Saddle box | Optional | |
Dimensions | Inner Dimension (L x W x H) | 5925 x 1930 x 2155mm |
Body Dimension (L x W x H ) | 5950 x 1980 x 2230mm | |
Overall Dimension(L x W x H) | 6800 x 2270 x 2590mm |
