- Size: 30
- Place of Origin: China
- Brand Name: truckmore
- Model Number: 2HAL-D
- Weight: 1600.000 kg
Overall Dimensions | 4970*2270*2590mm | |
Dimension of Body | 4120*1980*2230mm | |
Maximum Internal Dimension of body | 3095*1930*2155mm | |
Chassis | hot-galvanized RHS (3.5mm-4.0mm) | |
Frame | hot-galvanized RHS(2.5mm) | |
Body | galvanized(iron) sheet(1.0mm-1.5mm) | |
Roof | glass fibred reinforced plastic 3475*1750mm | |
Wheel/Tyre | alloy wheels 185R14C | |
Spare Wheel | 1,mounted outside | |
Suspension | 7-leaf plate spring suspension(400KG/leaf),Independent | |
Axles | trailer axles | |
Brake System | double axles electric brake with break away systems | |
Front Window | 1220*610 polycarbonate wind shield | |
Side Window | two rectangle(diamond) sliding windows, one each side | |
Side Door | one | |
Turn Lights | two each side(except tail lights) | |
Tail Lights | two sets | |
Horse Divider | soft cushion and fully padded with stallion head divider | |
Decorative Front panel | aluminium checkered plate 1.2mm | |
Mudguard | protected by aluminium checkered plate | |
Pedal Plate | decorated with aluminium checkered plate | |
External Tie Hooks | four, two each side | |
Jockey Wheel | swing-up jockey wheel | |
A kitchen | with a cupboard and all appliance from yourself | |
Roof Vents | two vents | |
Saddle Stents | two saddle stents in saddle box | |
Toolbox | none | |
Front Rug Rack | none | |
Front Tack Box | none | |
Tailgate(upper) | 1800*1065mm, pneumatic spring-loaded | |
Tailgate/Ramp Door | 1800*1210mm, pneumatic spring-loaded,10mm rubber matting | |
Horse Area | 10mm rubber floor | |
Side Area Inner | 6mm rubber matting | |
Taillight Mounting Plate | aluminium checkered plate | |
Fold Up Beds | none | |
